Portable Ultrasound Scanner WR-MD020

WR-MD020 is a good ultrasound scanner with carryscan design.High-resolution image,elegant appearance,complete function and humanized operation meet customers needs.

Features:
Full digitalbeam former.
Large capacity cine loop & image storage.
10.7 inches TFT LCD.
Wide-board probe with multiple frequency.
Backlit keyboard,comfortable for dark operatingroom.
(THI) Tissue harmony imaging.
8-segment TGC assuring delicate image adjustments.
Rich functions for image procession.
Probe automatic recognized.
Punctureguider.
Multi-output for image transfer.
Specifications:
Monitor: 10.7 inches color LCD
Image flip: up/down, left/right,black/white
Display mode: B, B+B, B+M, M, 4B
Image process: GAMA, image smoothen, THI,zoom
Gray scale: 256 level
Power supply: AC110~240V/50Hz
Cine loop: ≥500frames
Battery: Li-ion 14V
Permanent storage: 64 images
.W: 3.5KG (including battery)
Scan angle: Adjustable
Measurement: 300(L)*250(W)*80（H）mm
Scan depth: 40~240mm

Optional：
5.0MHz Micro-convex probe
6.5MHz Vet rectal probe
3.5MHz Convex probe
Carry bag
Rechargeable battery
