Specification

Magnification:

40x-1600x

Eyepiece,

WF10X/20mm,diopter adjustable

Eyepiece,

WF16X/15mm,diopter adjustable

Digital viewing head

Digital compensation binocular head, 45° inclination, buit in CCD/CMOS camera

Nosepiece

4 holes revolving nosepiece, ineard

195N Achromatic Objective

E Plan 4x

E Plan 10x

E Plan 40x

E Plan 100x

Focusing system

coaxial coarse &fine focusing knob, coarse focuing range 22mm, fine focusing graduation 0.002mm

Stage

Double layer mechanical stage 140X132mm,moving range 70X50mm, can hold 2 slides

Condenser

Abbe condenser N.A=1.25, Iris diaphragm, center adjustable, with height adjust knob

Bottom light

LED 3W, brightness adjustable

Power

customized

Filter

White, blue, yellow, each one

Prepared slide

Plant 1 piece

CMOS camera

Digital 1.3 mega pixels, 1280X1024

Digital 2.0 mega pixels, 1600x1200

Digital 3.1 mega pixels, 2048x1536

Signal output

Digital USB2.0

Software

PHMIAS Ver3.0
