Type

WR-LD015

Eyepieces

High point of view,wide angle WF 10X/Φ20mm,WF 16X\Φ16mm

Objectives

Infinite Plan Achromatic Objectives,HC PLAN 4X,10X,40X(S),100X(SO)

Viewing Head

Infinite gemel-style trinocular tube,inclined 30 degree,360 degree rotatable

Epi-fluorescence illuminum system

3W Highlight monochrome LED,brightness adjustable,Each Monochrome LED light emission wavelength is: UV light 365nm ~ 370nm, purple 395nm ~ 400nm, blue 450nm ~ 455nm, green: 520nm ~ 530nm

Fluorescent filter group: B blue, G green, V purple, U UV light

LED light source and fluorescent filter group can be free to switch

Nosepiece

Inner inclined quadruple nosepiece,ball locating

Focusing system

Coaxial coarse & fine focusing knob, coarse focusing range 20mm, fine focusing graduation 0.001mm,with the hand wheel tightness adjustment,random limit locking mechanism

Stage

Double layer mechanical stage 188x145mm, moving range  76x54mm, can hold 2 slides

Condenser

Abbe condenser N.A.=1.25, iris diaphragm, center adjustable, with height adjust knob

Transmission lighting system

Carat lighting,LED 3W/1A or halogen lamp 6V/30W (No standard)optional

Power

External voltage stabilized power supply adapter,Input AC90-240V,Output DC6.5V/5A

Optional

Camera

CCD condenser
