Specification

Viewing Head

 Compensation Free Trinocular Head, Inclined 45°(50mm-75mm)

Eyepiece

 WF10×/22mm

Objective

 Long working distance plan achromatic objectives: 4×,10×(phase contrast),20×(phase contrast),40×(s)

Stage

 Double layer mechanical stage

 Stage Size: 242mm×172mm Central stage: Φ110mm

 Moving Range: 75mm×40mm

Filter

 N.A.0.3 Abbe Condenser with iris diaphragm, Working Distance:75mm

Focusing

 Coaxial coarse and fine focusing system With tension adjustment  Fine focusing scale value 0.002mm

Light Source

 Transmission Illumination: Halogen Bulb 12V/30W, Adjustable Brightness

Epi-Fluorescent lllumination:220V(110V) Ultra-high pressure MercuryLamp100W/DC. Digital display mercury lamp constant power

Fluorescence attachment

B,G Wave band

Optional Accessory

 1.3Mega,2.0 Mega,3.0 Mega,5.0 Mega,pixels CMOS Digital camera eyepiece

 Objective:40×phase contrast

 U,V Wave band

 Photography attachment and CCD Adapter0.5×,0.57×,0.75×
