Part name

Specification

WR-LD013-1

WR-LD013-2

Magnification

40x-400x

·

·

Eyepieces

WF10x/22mm

·

·

eyepiece interface 30mm,  10mm parfocal distance 10mm

·

·

Viewing head

trinocular, inclined 30 degree

·

·

Nosepiece

inner inclined quintuple nosepiece, ball bearing inner locating

·

·

Objective

Phase contrast 10X/0.25

·

 achromatic objective 10X/0.25, WD:4.27mm

·

·

achromatic objective 20X/0.4, (S), WD:8mm

·

·

achromatic objective 40X/0.6, (O)(S), WD:3.5mm

·

·

Focusing system

coarse and fine with tensionadjustable and up stop,minimum division of fine focusing is 2um, Effective distance is 8mm

·

·

Stage

double layer mechanical stage, size 300X170mm,moving range 75mmX132.5mm

·

·

Condenser

long working distance condenser, working distance:70mm

·

·

Light

LED 9W

·

·

Voltage plug

design for client

·

·

 Filter

 frosted grass and blue filter

·

·
