Item

WR-LD012

Eyepiece

Large view field WF10X(18mm)

Objective

Long distance achromatic objective lens (without cover glass)PL L5X/0.12

Long distance achromatic objective lens (without cover glass) PL L10X/0.25

Long distance achromatic objective lens (without cover glass) PL L40X/0.6

Long distance achromatic objective lens (without cover glass) PL L60X/0.75

Eyepiece tube

Trinocular eyepiece,30° inclined(built-in polarizer for switching)

Epi-illumination system

6V 20W halogen lamp, brightness adjustable

Epi-illuminator with view field aperture, aperture stop, polarizer, filters(yellow, green, and blue), and frosted glass

Focusing

Coarse micro coaxial focusing,jogging lattice value: 1μm, coarse fastening and loosening adjustable, with locking and fastening device.

  Nose-piece

Four holes(inward roller positioning)

Working stage

Two-layer mechanical mobile type(Size 185mm×140mm,moving range 75mm×50mm)

Metallographic analysis software

Metallographic analysis software system JX2015version

3 million pixel image camera

0.5X adaptor

Micrometer(precision: 0.01mm)
