Biological Microscope

M

B

T

Head

 Monocular Head, 30° Inclined, 360° Rotatable

√

 Sliding Binocular Head, Interpupillary Distance: 55-75mm, 45° Inclined, 360°  Rotatable, Left & Right Diopter Adjustable

√

 Sliding Trinocular Head, Interpupillary Distance:55-75mm, 45° Inclined, 360°  Rotatable, Left & Right Diopter Adjustable

√

Eyepiece

 Wide Field Plan WF10X

√

√

√

Objective

 Achromatic 4X

√

√

√

 Achromatic 10X

√

√

√

 Achromatic 40X(S)

√

√

√

 Achromatic 100X(S,Oil)

√

√

√

Nosepiece

 Quadruple Nosepiece

√

√

√

Stage

 Double Layers Mechanical Stage 140X155mm/75X50mm

√

√

√

Condenser

 Abbe Condenser N.A.1.25, Φ2-Φ30mm Iris Diaphragm, with Φ32 Filter Holder

√

√

√

Focusing

 Coaxial Coarse & Fine Focusing Adjustable Mechanism 25mm, Precision  0.002mm

√

√

√

Light Source

 LED Lamp 1W/ Halogen Brightness Adjustable

√

√

√

Weight

 Gross Weight 7Kg, Net Weight 6Kg

√

√

√
